CoCo Disk BASIC disk structure – part 3

Leave a reply

See also: part 1, part 2 and part 3.

A correction, and discovering the order RS-DOS writes things…

A correction from part 2… This example program had “BIN” and “ASC” mixed up. 0 should represent BINary files, and 255 for ASCii files. I fixed it in line 920. (I will try to edit/fix the original post when I get a moment.)

10 ' FILEINFO.BAS
20 '
30 ' 0.0 2023-01-25 ALLENH
40 ' 0.1 2023-01-26 ADD DR
50 ' 0.2 2023-01-27 MORE COMMENTS
55 ' 0.3 2025-11-18 BIN/ASC FIX
60 '
70 ' E$(0-1) - SECTOR HALVES
80 ' FT$ - FILE TYPE STRINGS
90 '
100 CLEAR 1500:DIM E$(1),FT$(3)
110 FT$(0)="BPRG":FT$(1)="BDAT":FT$(2)="M/L ":FT$(3)="TEXT "
120 '
130 ' DIR HOLDS UP TO 72 ENTRIES
140 '
150 ' NM$ - NAME
160 ' EX$ - EXTENSION
170 ' FT - FILE TYPE (0-3)
180 ' AF - ASCII FLAG (0/255)
190 ' FG - FIRST GRANULE #
200 ' BU - BYTES USED IN LAST SECTOR
210 ' SZ - FILE SIZE
220 '
230 DIM NM$(71),EX$(71),FT(71),AF(71),FG(71),BU(71),SZ(71)
240 '
250 INPUT "DRIVE";DR
260 '
270 ' FILE ALLOCATION TABLE
280 ' 68 GRANULE ENTRIES
290 '
300 DIM FA(67)
310 DSKI$ DR,17,2,G$,Z$:Z$=""
320 FOR G=0 TO 67
330 FA(G)=ASC(MID$(G$,G+1,1))
340 NEXT
350 '
360 ' READ DIRECTORY
370 '
380 DE=0
390 FOR S=3 TO 11
400 DSKI$ DR,17,S,E$(0),E$(1)
410 '
420 ' PART OF SECTOR
430 '
440 FOR P=0 TO 1
450 '
460 ' ENTRY WITHIN SECTOR PART
470 '
480 FOR E=0 TO 3
490 '
500 ' DIR ENTRY IS 32 BYTES
510 '
520 E$=MID$(E$(P),E*32+1,32)
530 '
540 ' NAME IS FIRST 8 BYTES
550 '
560 NM$(DE)=LEFT$(E$,8)
570 '
580 ' EXTENSION IS BYTES 9-11
590 '
600 EX$(DE)=MID$(E$,9,3)
610 '
620 ' FILE TYPE IS BYTE 12
630 '
640 FT(DE)=ASC(MID$(E$,12,1))
650 '
660 ' ASCII FLAG IS BYTE 13
670 '
680 AF(DE)=ASC(MID$(E$,13,1))
690 '
700 ' FIRST GRANUAL IS BYTE 14
710 '
720 FG(DE)=ASC(MID$(E$,14,1))
730 '
740 ' BYTES USED IN LAST SECTOR
750 ' ARE IN BYTES 15-16
760 '
770 BU(DE)=ASC(MID$(E$,15,1))*256+ASC(MID$(E$,16,1))
780 '
790 ' IF FIRST BYTE IS 255, END
800 ' OF USED DIR ENTRIES
810 '
820 IF LEFT$(NM$(DE),1)=CHR$(255) THEN 1390
830 '
840 ' IF FIRST BYTE IS 0, FILE
850 ' WAS DELETED
860 '
870 IF LEFT$(NM$(DE),1)=CHR$(0) THEN 1370
880 '
890 ' SHOW DIRECTORY ENTRY
900 '
910 PRINT NM$(DE);TAB(9);EX$(DE);"  ";FT$(FT(DE));" ";
920 IF AF(DE)=0 THEN PRINT"BIN"; ELSE PRINT "ASC";
930 '
940 ' CALCULATE FILE SIZE
950 ' SZ - TEMP SIZE
960 ' GN - TEMP GRANULE NUM
970 ' SG - SECTORS IN LAST GRAN
980 '
990 SZ=0:GN=FG(DE):SG=0
1000 '
1010 ' GET GRANULE VALUE
1020 ' GV - GRAN VALUE
1030 '
1040 GV=FA(GN)
1050 '
1060 ' IF TOP TWO BITS SET (C0
1070 ' OR GREATER), IT IS THE
1080 ' LAST GRANULE OF THE FILE
1090 ' SG - SECTORS IN GRANULE
1100 '
1110 IF GV>=&HC0 THEN SG=(GV AND &H1F):GOTO 1280
1120 '
1130 ' ELSE, MORE GRANS
1140 ' ADD GRANULE SIZE
1150 '
1160 SZ=SZ+2304
1170 '
1180 ' MOVE ON TO NEXT GRANULE
1190 '
1200 GN=GV
1210 GOTO 1040
1220 '
1230 ' DONE WITH GRANS
1240 ' CALCULATE SIZE
1250 '
1260 ' FOR EMPTY FILES
1270 '
1280 IF SG>0 THEN SG=SG-1
1290 '
1300 ' FILE SIZE IS SZ PLUS
1310 ' 256 BYTES PER SECTOR
1320 ' IN LAST GRAN PLUS
1330 ' NUM BYTES IN LAST SECT
1340 '
1350 SZ(DE)=SZ+(SG*256)+BU(DE)
1360 PRINT " ";SZ(DE)
1370 DE=DE+1
1380 NEXT:NEXT:NEXT
1390 END
1400 ' SUBETHASOFTWARE.COM

To test this routine, I created a program that let me type a file size (in bytes) and then it would make a .TXT file with that size as the filename (i.e, for 3000 bytes, it makes “3000.TXT”) and then I could run it through this program and see if everything matched.

It opens a file with the size as the filename, then writes out “*” characters to fill the file. This will be painfully slow for large files. If you want to make it much faster, share your work in a comment.


10 ' MAKEFILE.BAS
20 '
30 ' 0.0 2025-11-18 ALLENH
40 '
50 INPUT "FILE SIZE";SZ
60 F$=MID$(STR$(SZ),2)+".TXT"
70 OPEN "O",#1,F$
80 FOR A=1 TO SZ:PRINT #1,"*";:NEXT
90 CLOSE #1
100 DIR
110 GOTO 50
120 ' SUBETHASOFTWARE.COM

I was able to use this program in the Xroar emulator to create files of known sizes so I could verify the FILEINFO.BAS program was doing the proper thing.

It seems to be, so let’s move on…

A funny thing happened on the way to the disk…

I have been digging in to disk formats (OS-9 and RS-DOS) lately, and learning more things I wish I knew “back in the day.” For instance, I was curious how RS-DOS allocates granules (see part 1) when adding files to the disk. I wrote a test program that would write out 2304-byte blocks of data (the size of a granule) full of the number of the block. i.e., for the first write, I’d write 2304 0’s, then 2304 1’s and so on. My simple program looks like this:

10 'GRANULES.BAS
20 OPEN "O",#1,"GRANULES.TXT"
30 FOR G=0 TO 67
40 PRINT G;
50 T$=STRING$(128,G)
60 FOR T=1 TO 18
65 PRINT ".";
70 PRINT #1,T$;
80 NEXT
90 PRINT
100 NEXT
110 CLOSE #1

I ran this on a freshly formatted disk and let it fill the whole thing up. The very last write errors with a ?DF ERROR (disk full) so it never makes it to the close. I guess you can’t write that last byte without an error?

Now I should be able to look a the bytes on the disk and see where the 0’s went, the 15’s went, and so on, and see the order RS-DOS allocated those granules.

I made a simple test program for this:

0 'GRANDUMP.BAS
10 CLEAR 512
20 FOR G=0 TO 67
30 T=INT((G)/2):IF T>16 THEN T=T+1
40 IF INT(G/2)*2=G THEN S1=10:S2=18 ELSE S1=1:S2=9
50 'PRINT "GRANULE";G;TAB(13);"T";T;TAB(20);"S";S1;"-";S2
54 DSKI$0,T,S1,A$,B$
55 PRINT "GRANULE";G;ASC(A$)
60 NEXT G

Ignore the commented out stuff. Initially I was just getting it to convert a granule to Track/Sectors with code to skip Track 17 (FAT/Directory). And, to be honest, I had an AI write this and I just modified it ;-)

I then modified it to PRINT#-2 to the printer, and ran it in Xroar with the printer redirected to a text file. That gave me the following output:

GRANULE 0  67
GRANULE 1  66
GRANULE 2  65
GRANULE 3  64
GRANULE 4  63
GRANULE 5  62
GRANULE 6  61
GRANULE 7  60
GRANULE 8  59
GRANULE 9  58
GRANULE 10  57
GRANULE 11  56
GRANULE 12  55
GRANULE 13  54
GRANULE 14  53
GRANULE 15  52
GRANULE 16  51
GRANULE 17  50
GRANULE 18  49
GRANULE 19  48
GRANULE 20  47
GRANULE 21  46
GRANULE 22  45
GRANULE 23  44
GRANULE 24  43
GRANULE 25  42
GRANULE 26  41
GRANULE 27  40
GRANULE 28  39
GRANULE 29  38
GRANULE 30  37
GRANULE 31  36
GRANULE 32  1
GRANULE 33  0
GRANULE 34  3
GRANULE 35  2
GRANULE 36  5
GRANULE 37  4
GRANULE 38  7
GRANULE 39  6
GRANULE 40  9
GRANULE 41  8
GRANULE 42  11
GRANULE 43  10
GRANULE 44  13
GRANULE 45  12
GRANULE 46  15
GRANULE 47  14
GRANULE 48  17
GRANULE 49  16
GRANULE 50  19
GRANULE 51  18
GRANULE 52  21
GRANULE 53  20
GRANULE 54  23
GRANULE 55  22
GRANULE 56  25
GRANULE 57  24
GRANULE 58  27
GRANULE 59  26
GRANULE 60  29
GRANULE 61  28
GRANULE 62  31
GRANULE 63  30
GRANULE 64  33
GRANULE 65  32
GRANULE 66  35
GRANULE 67  34

Now I can see the order that RS-DOS allocates data on an empty disk.

The number in the third column represents the value of the bytes written to that 2304 granule. When I see “GRANULE 67” contains “34” as data, I know it was the 35th (numbers 0-34) granule written out.

Granules 0-33 are on tracks 0-16, then track 17 is skipped, then the remaining granules 34-67 are on tracks 18-34.

You can see that RS-DOS initially writes the data close to track 17, reducing the time it takes to seek from the directory to the file data. This makes sense, though as a teen, I guess I had some early signs of O.C.D. because I thought the directory should be at the start of the disk, and not in the middle ;-)

I brought this data into a spreadsheet, then sorted it by the “data” value (column 3). This let me see the order that granules are allocated (written to). I will add some comments:

GRANULE	33	0 <- first went to gran 33
GRANULE	32	1 <- second went to gran 32

...then it starts writing after Track 17...

GRANULE	35	2 <- third went to gran 35
GRANULE	34	3 <- fourth went to gran 34
GRANULE	37	4
GRANULE	36	5
GRANULE	39	6
GRANULE	38	7
GRANULE	41	8
GRANULE	40	9
GRANULE	43	10
GRANULE	42	11
GRANULE	45	12
GRANULE	44	13
GRANULE	47	14
GRANULE	46	15
GRANULE	49	16
GRANULE	48	17
GRANULE	51	18
GRANULE	50	19
GRANULE	53	20
GRANULE	52	21
GRANULE	55	22
GRANULE	54	23
GRANULE	57	24
GRANULE	56	25
GRANULE	59	26
GRANULE	58	27
GRANULE	61	28
GRANULE	60	29
GRANULE	63	30
GRANULE	62	31
GRANULE	65	32
GRANULE	64	33
GRANULE	67	34
GRANULE	66	35

...now that it has written to the final Track 35 (gran 66-67)...

GRANULE	31	36 <- before Track 17 and the original writes.
GRANULE	30	37
GRANULE	29	38
GRANULE	28	39
GRANULE	27	40
GRANULE	26	41
GRANULE	25	42
GRANULE	24	43
GRANULE	23	44
GRANULE	22	45
GRANULE	21	46
GRANULE	20	47
GRANULE	19	48
GRANULE	18	49
GRANULE	17	50
GRANULE	16	51
GRANULE	15	52
GRANULE	14	53
GRANULE	13	54
GRANULE	12	55
GRANULE	11	56
GRANULE	10	57
GRANULE	9	58
GRANULE	8	59
GRANULE	7	60
GRANULE	6	61
GRANULE	5	62
GRANULE	4	63
GRANULE	3	64
GRANULE	2	65
GRANULE	1	66
GRANULE	0	67 <- last write at the very first gran

And down the rabbit hole I go. Again. I have tasked an A.I. with creating some simple scripts to manipulate RS-DOS disk images (just for fun; the toolshed “decb” command already exists and works great and does more). While I understood the basic structure for an RS-DOS disk, I did not understand “how” RS-DOS actually allocated those granules. Now I have some insight. Perhaps I can make my tools replicate writing in the same way that RS-DOS itself does.

Look for a part 4. I have some more experiments to share.

To be continued…

Do you want to build a snow flake? Logiker 2025!

2 Replies

The 2025 edition of the Logiker programming challenge has been announced via a YouTube video:

This year’s pattern is a snowflake, and I am very curious to see the approaches people come up with in BASIC to do this. I have some ideas, but none of them seem small.

This 19×19 image won’t fit on a CoCo’s 32×16 screen, but the challenge allows it to scroll off as long as it was printed to match. Using the 40/80 column screen on the CoCo 3 would work well.

Here is the info page for the challenge:

https://logiker.com/Vintage-Computing-Christmas-Challenge-2025

I somehow completely missed out on last year’s challenge, which was a present box, so maybe I’ll find some time to experiment with this one. I’ve never “entered” the challenge, but have blogged attempts here.

Are you in? Let’s get coding!

Coding standards and talking myself into snake_case…

6 Replies

Obviously, things done “today” can be quite different than how things were done 30 years ago, especially in regards to computers. Is it strange that out of all the places I’ve worked where I wrote code that only one of them had an actual “coding standard” we had to follow? (And that was at a giant mega-corporation.) All the others seemed to have folks who just carried on how things were, for the most part, or were given the freedom to code as they wanted as long as they followed some specific system (such as “Clean Code” at a startup I worked at).

My day job has been undertaking an official coding standard. I started by documenting how things were done in the millions of lines of code we maintain. Over my years here, I have introduced some things from the mega-corporation’s standards into our code base, such as prefixing static variables with “s_” or globals with “g_” or similar.

But why reinvent the wheel? I thought it would make a lot more sense to find an existing standard that applied to embedded C programming and just adopt it. That led me to this:

https://barrgroup.com/embedded-systems/books/embedded-c-coding-standard1

This document clearly states the “why” for any requirement it has, and I have learned a few things. Unlike most standards that are mostly cosmetic (how to name functions or variables, how wide is a tab, etc.), this one focuses on bug detection, bug reduction and making code easier to review.

Which brings me to snake case…

https://en.wikipedia.org/wiki/Snake_case

Most places I have worked use camelCase, where all words are ran together (no spaces) with the first letter in lowercase, then all subsequent words starting with uppercase. itWorksButCanBeHardToRead.

The mega-corp standard I worked under would refer to “camel case starting with an uppercase letter,” which I have since learned is known as PascalCase. ItCanHaveTheSameProblem when the eyes have to un-smush all the letters.

snake_case is using lowercase words separated by underlines. A variant, SCREAMING_SNAKE_CASE uses all uppercase. (I never knew the name of that one, but most places I worked use that for #defines and macros and such.)

…and I expect someone will comment with even more naming conventions than I have encountered.

Do. Or do not. There is no try.

Beyond “how stuff looks,” some suggestions actually matter. Something I only started doing in recent times is when you put the constant on the left side of a comparison like this:

if (42 == answer)
{
    // Ultimate!
}

I saw this for the first time about a decade ago. All the code from a non-USA office we interacted with had conditions written “backwards” like that. I took an instant dislike to it since it did not read naturally. I mean who says “if 225 pounds or more is your weight, you can’t ride this scooter”?

However, all it takes is a good argument and I can flip on a dime. This flip was caused by finding multiple bugs in code where the programmer accidentally forgot one of the equals:

if (answer = 42)
{
    // Ultimate?
}

If you use a modern compiler and have compiler warnings enabled, it should catch that unintended variable assignment. But, if you are using a “C-Like” embedded compiler that is missing a lot of modern features, it probably won’t. Or, if even you are running GCC with defaults:

https://onlinegdb.com/pv5Yz24t2

And thus, I broke my habit of making code that “reads more naturally” and started writing comparisons backwards since the compiler will fail if you do “42 = answer”.

This week, I learned they refer to this as Yoda conditions. Of course they do.

https://en.wikipedia.org/wiki/Yoda_conditions

Snakes. Why did it have to be snakes?

This week I read one sentence that may make me get away from camelCase and PascalCase and go retro with my naming convention. It simply had to do with readability.

is_adc_in_error is very easy to read. I’d say much easer than IsAdcInError which looks like some gibberish and requires you to focus on it. If anyone else is going to review the code, being able to “parse” it easier is a benefit.

I am almost convinced, even if I personally dislike it.

Give me some reasons to stick with camelCase or PascalCase, and let’s see if any of them are more than “’cause it looks purtier.” (For what its worth, I’ve seen camelCase for global functions, and CamelCase for static functions.)

Awaiting your responses…

Open Micro Works Digisector DS-69 digitizer .PIX files in GIMP

Leave a reply

Step 1: Rename the .PIX file so it has the extension .data. This is needed for GIMP to recognize it as a “raw” data file.

Step 2: Open this image in GIMP by expanding “Select File Type” and choosing Raw image data. That should allow the .data file to show up in the browser to open it.

Step 3: The file will open and you must adjust settings to tell GIMP more about the image. Under Pixel format, select Grayscale 4-bit. For the Width and Height, set them to 256 (if it is a 32K file) or 128 (if it is 8K). Now you should be able to Open the image.

Step 4: With the image open, you will need to Invert it to get the colors correct (Colors -> Invert) and rotate the image clockwise (Image -> Transform -> Rotate 90 clockwise).

Step 5: That should give you a 256×256 or 128×128 16-greyscale image you can now save out in whatever format you wish. GIMP can save based on the extension you give it when exporting. (File -> Export As… then change the extension to .PNG or .GIF or whatever.)

Tada!

Neat.

Or, I had A.I. write this quick conversion script… It can convert one file at a time, or run it in a directory with .PIX files and it will do them all. It currently only supports the 128×128 16-grey and 256×256 16-grey photos. I recall there was a 64-grey mode, so if I find one of those images, I will update the script to do them, too.

#!/usr/bin/env python3
import sys
import glob
from PIL import Image

def convert_pix(pix_file):
    with open(pix_file, 'rb') as f:
        data = f.read()

    if len(data) == 32768:
        width, height = 256, 256
    elif len(data) == 8192:
        width, height = 128, 128
    else:
        print(f"Invalid file size for {pix_file} (expected 8192 or 32768 bytes)")
        return

    pixels = []
    for byte in data:
        pixels.append(byte >> 4)
        pixels.append(byte & 0x0F)

    # Create image
    img = Image.new('P', (width, height))
    img.putdata(pixels)

    # Rotate right 90 degrees (CW)
    img = img.rotate(-90)

    # Invert colors
    inverted_pixels = [15 - p for p in img.getdata()]
    img.putdata(inverted_pixels)

    # Set greyscale palette
    palette = []
    for i in range(16):
        v = i * 255 // 15
        palette.extend([v, v, v])
    img.putpalette(palette)

    # Save as PNG
    output_file = pix_file.replace('.PIX', '.png').replace('.pix', '.png')
    img.save(output_file)
    print(f"Converted {pix_file} ({width}x{height}) to {output_file}")

def main():
    if len(sys.argv) == 1:
        pix_files = glob.glob('*.PIX') + glob.glob('*.pix')
        if not pix_files:
            print("No .PIX files found in current directory")
            sys.exit(1)
    else:
        pix_files = sys.argv[1:]

    for pix_file in pix_files:
        convert_pix(pix_file)

if __name__ == "__main__":
    main()

You can find it on my GitHub along with documentation on what all it needs to run:

https://github.com/allenhuffman/DS69-PIX-to-PNG

Good luck!

Wanted: disassembly of Sub-Etha Software’s MultiBoot

11 Replies

Updates:

  • 2025-11-20 – Thanks to a comment from Jerry Stratton, I have the start of a disassembly for the “DOS” code which would load at $2600. Article updated with what I have, so far.
  • 2025-11-21 – Updating assembly to include the raw bytes that were used.
  • 2025-11-21 – Updating the assembly again, using a tool John Linville pointed me to.
  • 2025-11-21 – Removing asm from this page and linking to the GitHub link instead.

To this date I still think one of the most useful products Sub-Etha Software ever created was MultiBoot. For CoCo hard drive users of the era, most of us had to boot from a floppy disk. That boot disk would contain the necessary drivers to access the hard drive. With boot files, “one size does not fit all” so most of us had a stack of them — one for running a BBS with serial drivers installed, one with the Sierra Online drivers for playing those games, one with all the graphics drivers for that stuff, etc.

MultiBoot allowed putting multiple boot files on one floppy disk. Type “DOS” and a menu is displayed. Choose the one you want, then that boot file is made active and the process continues.

MultiBoot was written by myself and Sub-Etha co-founder, Terry S. Todd. I wrote the OS-9 frontend in C, and Terry wrote the actual MultiBoot code in RS-DOS assembly. He would then provide that code to me as data, then my C front end program would “install” it by copying it out to the boot sector of the boot disk.

That code looks like this in the MultiBoot source code:

char mb_sec34_1[] = { /* Terry's RS-DOS DOS startup code... 50 bytes */
   79,83,134,13,151,211,204,56,0,221,209,12,211,142,0,234,204,2,0,237,132,
   134,33,214,211,237,2,220,209,237,4,173,159,192,4,109,6,38,8,76,129,61,37,
   221,126,57,0,126,215,9
};

char mb_sec33_15[] = { /* Terry's RS-DOS MultiBoot code V1.12... 512 Bytes */
   142,56,0,16,142,38,0,236,129,237,161,140,57,0,37,247,23,1,152,23,1,171,
   32,32,32,32,32,32,32,32,77,117,108,116,105,66,111,111,116,32,86,49,46,49,
   50,13,32,98,121,32,84,101,114,114,121,32,84,111,100,100,32,38,32,65,108,
   108,101,110,32,72,117,102,102,109,97,110,13,32,32,32,32,32,67,111,112,121,
   114,105,103,104,116,32,40,67,41,32,49,57,57,51,32,98,121,13,32,32,32,32,
   32,32,32,83,117,98,45,69,116,104,97,32,83,111,102,116,119,97,114,101,13,
   0,16,142,5,192,16,159,136,23,1,53,32,32,32,32,32,85,115,101,32,85,80,47,
   68,79,87,78,32,116,111,32,115,99,114,111,108,108,13,91,69,78,84,69,82,93,
   32,83,101,108,101,99,116,115,32,32,32,91,66,82,69,65,75,93,32,81,117,105,
   116,115,0,246,58,235,23,1,16,206,4,164,246,58,255,16,39,0,209,240,58,235,
   193,8,37,2,198,8,52,20,223,136,189,58,208,53,20,48,136,32,51,200,32,90,
   38,238,182,58,234,176,58,235,198,32,61,195,4,163,31,1,134,106,167,132,16,
   190,58,253,49,63,38,5,50,98,22,0,151,173,159,160,0,39,241,198,96,231,132,
   198,255,129,94,39,17,129,10,39,36,129,13,39,62,129,3,38,197,15,113,126,
   140,27,182,58,234,39,187,247,1,85,74,183,58,234,177,58,235,36,3,122,58,
   235,22,255,126,182,58,234,76,177,58,255,36,160,247,1,86,183,58,234,182,
   58,235,139,7,177,58,234,36,228,124,58,235,32,223,246,58,234,92,141,112,
   48,27,52,16,142,0,234,204,2,0,237,132,204,0,1,237,2,204,1,218,237,4,173,
   159,192,4,109,6,38,79,16,174,4,49,168,21,53,64,198,5,166,192,167,160,90,
   38,249,134,3,167,132,173,159,192,4,109,6,38,50,126,38,2,134,87,183,149,
   201,134,16,183,255,34,204,63,0,253,255,188,189,246,82,126,169,40,174,228,
   166,128,39,6,173,159,160,2,32,246,175,228,57,166,128,39,251,173,159,160,
   2,32,246,126,215,9,142,59,0,93,39,236,48,136,32,90,38,250,57,0,0,0,0,0,
   0,0,0,0,0,0,0,0,0,0,0,0,0,0,66,66,0
};

Are there any 6809 disassembler gurus out there that might take this data and reverse it back into 6809 assembly source code?

Sadly, the only source code from Terry that I have found is that for his MultiBasic product. I cannot even find the master disks for his InfoPatch, and I do not think I ever had sources to ShadowBBS, OS9Term or anything else he wrote.

Thank you for your attention to this matter.

Disassemblies

The “DOS” code would load into memory at &H2600. The first two bytes must be “OS”, and indeed that matches the first two bytes in the data. Per a suggestion from Jerry Stratton, I wrote a program to POKE this data into memory, then used EDTASM Z-BUG to disassemble and do a bit of cleanup.

Where the “??” comment is was something Z-BUG could not decode. There is a value of 2 there. No cluck. BUT, I see a reference to DSKCON (C004) so I am betting if I look up how that works some of this code might make sense.

Help is appreciated!

NOTE: This is now updated using the f9dasm disassembler that John Linville pointed me to:

https://github.com/Arakula/f9dasm

Closer!

DOS Assembly (f9dasm)

https://github.com/allenhuffman/SubEthaSoftware/blob/main/OS-9/MultiBoot/asm/dos.asm

Multiboot Assembly (f9dasm)

https://github.com/allenhuffman/SubEthaSoftware/blob/main/OS-9/MultiBoot/asm/multiboot.asm

Updates

Tim Lindner pointed me to his online javascript disassembler. It did a great job right in the web browser:

https://www.macmess.org/follow9.html

Wanted: disassembly of Sub-Etha Software’s OS9Term

4 Replies

OS9Term was an RS-DOS terminal program written by Sub-Etha co-founder Terry S. Todd. It emulated the OS-9 text screen control codes. This not only included things like color, move cursor position, and underline, but also the overlay windows! OS-9 Level 2 “windows” on the text screen were all created by sending a series of escape code bytes. Terry’s program would let you dial in to an OS-9 machine using a modem and actually run text-mode windowing applications. I recall modifying my EthaWin interface with an option so it would not create its own window on startup. This allowed me to run the Towel disk utility remotely if I wanted. (EthaWin supported a mouse, but was designed so all functions – including the menu system – could be operated from the keyboard.)

It was a neat product, though I do not recall us selling very many copies. Too little, too late, I suppose.

The DSK image for this is up on the Color Computer Archive site:

https://colorcomputerarchive.com/repo/Disks/Applications/OS9Term%20%28Sub-Etha%20Software%29%20%28Coco%203%29.zip

As I went to find that link, I see this .zip has a Play Now button ;-) So here is a screenshot:

I would love to have a disassembly of this code, if anyone out there might be able and willing to take on such a task. The code is not all Terry’s. This program uses the bitbanger serial routines written by Ultimaterm’s Ken Johnston. At some point, Terry got in contact with him, and he provided his routines to Terry. Sub-Etha’s launch product, Shadow BBS, used the remote terminal driver written by Ken.

I don’t even know where to begin with a task like this, so I thought I’d post and see if anyone out there had some suggestions.

Thank you for your attention to this matter.

EXEC dispatch table for 6809 assembly

7 Replies

I am writing this so one of the 6809 experts who reads this can chime in and tell me a better way…

Often I post things so they can get in the search engines in case anyone else looks for that topic later. This is one of those.

Using DEF USR is a great way to put up to ten “easy to execute” routines in an assembly language program. Each of those routines can also do different things based on the numeric (or string) parameter passed in to the USR() call.

If you aren’t trying to be that fancy, but do want multiple functions for whatever reason, what methods are there? Please leave a comment with the best ways to call multiple functions using EXEC from Color BASIC.

Dispatch table

One method that comes to mind is using a dispatch table at the start of the machine language program. If the code is built to compile at &H3F00, then doing an EXEC &H3F00 will run that program. If there are more functions, you have to figure out where they are located and provide those address to the user. This is fine, until you make a change to the code and then those locations shift.

Instead, the start of the program could begin with a series of “branch always” instructions. For example:

            org     $7f00

start1      bra     install
start2      bra     uninstall

The branch always instruction is one byte, and it is followed by a second byte which is how many bytes away the function is. This makes each entry take two bytes. Thus, install is at &H7F00 and uninstall is at &H7F02. A whole series of functions could be done this way, and the user just has to remember which is which — &H7F00, &H7F02, &H7F04, etc. Having every two bytes be an entry makes it easy to remember.

; lwasm dispatch.asm -fbasic -odispatch.bas --map
; a09 -fbasic -odispatch.bas dispatch.asm

ORGADDR     equ     $3f00       ; Where program loads in memory

            org     ORGADDR

;------------------------------------------------------------------------------
; Absolute addresses of ROM calls
;------------------------------------------------------------------------------
CHROUT      equ	    $A002

;------------------------------------------------------------------------------
; This code can be called by EXEC/EXEC xxxx.
;------------------------------------------------------------------------------
; Dispatch table at the start of the program.
start1      bra     install
start2      bra     uninstall

install     leax    <msginst,pcr    ; X points to message
            bra     print           ; print will do the RTS
            ;rts

uninstall   leax    <msguninst,pcr  ; X points to message
            ;bra     print          ; print will do the RTS
            ;rts

;------------------------------------------------------------------------------
; PRINT subroutine. Prints the 0-terminated string pointed to by X plus CR
;------------------------------------------------------------------------------
print       lda     ,x+
            beq     printdone
            jsr     [CHROUT]
            bra     print
printdone   lda     #13
            jmp     [CHROUT]        ; JMP CHROUT will do an rts.
            ;rts

;------------------------------------------------------------------------------
; Data storage for the string messages
;------------------------------------------------------------------------------
msginst     fcc     "INSTALLED"
            fcb     0

msguninst   fcc     "UNINSTALLED"
            fcb     0

            end

One potential issue is that branch can only jump so far. If large functions are being called, you might find they cannot be reached from this dispatch table. One option would be to switch to “long branch”, but then you add more bytes and your dispatch table might be every three bytes – &H7F00, &H7F03, &H7F06, &H7F09, &H7F0C, etc.

That is a fine solution though every 2 may “look” nicer than every 3.

As a workaround, the dispatch table could remain short branches, but they go to a longer one just below it:

            org     $7f00

start1      bra     install
start2      bra     uninstall

; If a short branch cannot reach, it can call a second long branch:
uninstall   lbra    realuninstall

Above, perhaps “install” is within reach of the “bra”, but “uninstall” is too far away. Simply make the “bra uninstall” branch to a spot with a long branch. A few more bytes, a few more clock cycles, but now the dispatch table can remain “every 2 bytes”.

But there has to be a better way…

Leave your suggestions in the comments.

Until next time…

Bonus

Here is a BASIC loader for that example. RUN it, then EXEC &H7F00 or &H7F02 and be amazed. (Loader generated using Sean Conner’s a09 assembler.)

10 DATA32,2,32,5,48,140,21,32,3,48,140,26,166,128,39,6,173,159,160,2,32,246,134,13,110,159,160,2,73,78,83,84,65,76,76,69,68,0,85,78,73,78,83,84,65,76,76,69,68,0
20 CLEAR200,16127:FORA=16128TO16177:READB:POKEA,B:NEXT:

PEEK versus ARRAY in BASIC?

Leave a reply

Hat tip to Erico Monteiro for sending me down another quick benchmarking rabbit hole…

NOTE: This technique will work poorly for ASCII TEXT characters, since the PEEK value is not the same as the PRINT CHR$ value for some characters. It works fine with the graphics blocks (128-255). See the example at the end.

In general, I expect PEEK to be faster than looking up a variable. PEEK only has to process whatever is in the parentheses:

V=PEEK(1024)

Parsing the decimal 1024 can be slow. Using hex is faster (&H400). Using a variable can be even faster (unless there are a ton of variables BASIC has to scan to before finding the target one):

V=PEEK(L)

Erico just showed me technique using an array to store all the characters on the CoCo’s 32 column screen. PRINT@ can be used to put characters on the screen quickly, and when you want to PRINT@ the character somewhere else, you can PRINT@ whatever character used to be there by taking it from the array.

I expected PEEK would be faster than accessing elements of an array so I did a test where I looped through 512 characters using PEEK versus an array:

0' peek-vs-array.bas

10 TIMER=0:FORA=1024 TO 1536
20 Z=PEEK(A)
30 NEXT:PRINT TIMER

40 DIMB(511):TIMER=0:FOR A=0 TO 511
50 Z=B(A)
60 NEXT:PRINT TIMER

At line 10, I loop through all the locations of the 32×16 screen. One by one, Z is set to the value of that location. The value of the loop (1024-1536) matches the POKE/PEEK memory location of the screen.

At line 40, I have an array B() that would be loaded with all the bytes in the screen. The elements of the array (0-511) match the PRINT@ location of the screen.

My results:

123
127

Very close, though the array access is slightly slower. I confirmed PEEK is indeed faster … in this example.

Let’s pretend the loop is a “background” screen and we would PEEK and POKE to restore it versus PRINT@ from the array. (In this example, I am just getting what is there and printing that same thing there again, just for timing.)

0' peek-vs-array2.bas

10 TIMER=0:FOR A=1024 TO 1536
20 Z=PEEK(A):POKEA,Z
30 NEXT:PRINT TIMER

40 DIMB(511):TIMER=0:FOR A=0 TO 511
50 Z=B(A):PRINT@A,CHR$(Z);
60 NEXT:PRINT TIMER

And my results:

210
258

PEEK is faster here, too.

But I have now seen “real code” using this to put a CHR$() player graphic on the screen, and erase it as it moved across the screen (restoring the background as it goes) and the array was faster.

This is another example of why benchmarking a specific item is not always useful. For example, if using PRINT to put things on the screen, you are using the 0-511 location which matches the 0-511 array. If using PEEK, you have one location that is the display screen and another that would be the “saved” background screen. Each time you want to update something, you have to take the location (offset) and add it to the background (to get that one) and the foreground (to get that one). That doubling of math could make it slower versus PRINT@ using 0-511 and CHR$(B(x)) using the same 0-511.

So while PEEK is faster by itself, if you do that and need more math to use it, ARRAYs could win.

0' peek-vs-array3.bas

10 'FOREGROUND 0400-05FF (512)
11 'BACKGROUND 3E00-3FFF (512)
20 TIMER=0:FOR A=0 TO 511
30 Z=PEEK(&H3E00+A):POKE&H400+A,Z
40 NEXT:PRINT TIMER

50 DIM B(511):TIMER=0:FOR A=0 TO 511
60 Z=B(A):PRINT@A,CHR$(Z);
70 NEXT:PRINT TIMER

The first test loops 0-511 then uses “math” to calculate the background memory location, and more “math” to calculate the foreground memory location. Twice the math, twice the slowness.

The second does not match because the array and PRINT@ location.

333
259

Array is faster than two maths.

But, we can cut that math in half but have the FOR loop go through screen memory, then only add to that to get the background. &H3E00 (15872) background minus &H400 (1024) foreground is &H3A00 (14848). I am using hex because it is quicker for BASIC to parse an &H value than a decimal value.

0' peek-vs-array4.bas

10 'FOREGROUND 0400-05FF (512)
11 'BACKGROUND 3E00-3FFF (512)
20 TIMER=0:FOR A=1024 TO 1536
30 Z=PEEK(&H3A00+A):POKEA,Z
40 NEXT:PRINT TIMER

50 DIM B(511):TIMER=0:FOR A=0 TO 511
60 Z=B(A):PRINT@A,CHR$(Z);
70 NEXT:PRINT TIMER

Now that the first version only maths one time, it gets faster:

267
259

…but the array still beats it. The slower array/PRINT without math is faster than the faster PEEK/POKE with math.

How would you optimize this further? Comments if you got ’em…

Bonus Code

Use line 110 for keyboard control, or line 115 for random movement.

10 'ARRAYBAK.BAS
20 DIMB(511)
30 'KALEIDOSCOPE
40 CLS0:FORA=0TO42:X=RND(32)-1:Y=RND(16)-1:C=RND(8):SET(X,Y,C):SET(63-X,Y,C):SET(X,31-Y,C):SET(63-X,31-Y,C):NEXT
50 'SAVE SCREEN DATA TO ARRAY
60 FORA=0TO511:B(A)=PEEK(&H400+A):NEXT
70 'L=PRINT@ LOCATION
80 L=111
90 'MAIN LOOP
100 PRINT@L,"<O>";
110 'ONINSTR(" WASD",INKEY$)GOTO110,120,130,140,150
115 ONRND(4)GOTO120,130,140,150
120 NL=L-&H20:GOTO160
130 NL=L-1:GOTO160
140 NL=L+&H20:GOTO160
150 NL=L+1
160 IFNL<.THEN110
170 IFNL>&H1FC THEN110
180 PRINT@L,CHR$(B(L))CHR$(B(L+1))CHR$(B(L+2));:L=NL:GOTO100

Double Bonus

10 'ARRAYBAK.BAS
20 'L=NUMBER OF BLOCKS (0-7)
30 N=7
40 DIMB(511):DIML(N),C(N)
50 'KALEIDOSCOPE
60 CLS0:FORA=0TO42:X=RND(32)-1:Y=RND(16)-1:C=RND(8):SET(X,Y,C):SET(63-X,Y,C):SET(X,31-Y,C):SET(63-X,31-Y,C):NEXT
70 'SAVE SCREEN DATA TO ARRAY
80 FORA=0TO511:B(A)=PEEK(&H400+A):NEXT
90 'RANDOMIZE SHIP POSITIONS
100 FORA=0TON:L(A)=RND(510)-1:C(A)=143+16*A:NEXT
110 'MAIN LOOP
120 FORA=0TON
130 ONRND(4)GOTO140,150,160,170
140 NL=L(A)-&H20:GOTO180
150 NL=L(A)-1:GOTO180
160 NL=L(A)+&H20:GOTO180
170 NL=L(A)+1
180 IFNL<.THENNL=NL+&H1FC:GOTO210
190 IFNL>&H1FC THENNL=NL-&H1FC
200 L=L(A):PRINT@L,CHR$(B(L));:PRINT@NL,CHR$(C(A));:L(A)=NL
210 NEXT:GOTO120

Wanted: Sub-Etha Software’s InfoPatch for Infocom

Leave a reply

Sub-Etha Software sold a product called InfoPatch. It would take a stock TRS-80 Color Computer Infocom text adventure game and patch it to work on the CoCo 3 using the 80 column screen. As a bonus, it would speed up disk access by setting it to 6ms step rate.

I cannot find any master copies or documentation for this product, but I know we sold it. Here is what I wrote in my 1993 Middle America Fest trip report (from my book CoCoFest Chronicles).

Sub-Etha Software — There we were with our normal line of software including MiniBanners, CheckBook+, InfoPatch, N*Johnson Software, Carl England Utilities, and the new OSK products such as Etha-GUI and the new Write-Right “what you see is what you get” word processor which was the big hit for us. (Joel, you did a great job on this and I think you left many people quite impressed!)

– CoCoFest Chronicles, page 48.

I also mentioned it 1993 2nd Annual “Last” Chicago CoCoFest report:

Oh, just to get a fair plug in…”the same old stuff” includes MiniBanners, CheckBook+, Etha-GUI, and the recent InfoPatch which converts old CoCo 1/2 Infocom text adventures to run in 80 columns on a CoCo 3. We also had Carl England’s disk utilities and some old N*Johnson software. We promise MORE NEW ITEMS for the next Fest!

– CoCoFest Chronicles, page 65.

Here is text from an ad for the product:

InfoPatch by Terry Todd
Patch classic Infocom(tm) text games to run on 80 columns,
upper/lowercase, 6ms disk on CoCo 3.
RS-DOS Req: CoCo 3, Infocom Disk..........$ 9.95

It was still being advertised in 1995. From the Spring 1995 FARNA catalog:

As I go through my Sub-Etha archives, I find this ad copy from 1993 which notes this patch did not work on Seastalker:

NEW!  InfoPatch - Clever hack which patches old CoCo 1/2 Infocom text adventures (like The Hitchhiker's Guide to the Galaxy, Zork, and others) to work in 80 columns, double speed more on a CoCo 3. (Does not work with Seastalker!)  See Adventure Survivors newsletter.
Req:  CoCo 3, Disk Drive, Infocom Game Disk ........................ $ 9.95

And, it appears we launched this product in 1992. From that edition of the “What is Sub-Etha Software” flyer:

A few Sub-Etha ads ran in the Underground and just in time for the ’92 Atlanta CoCoFest Terry would return (but Mark would not be able to attend). Terry’s new offering was InfoPatch – a program to modify Infocom text adventures to run in 80 columns on a CoCo 3. This was also the show that gave life to the “PVC Nightmare” which spawned from the lack of fancy backdrops. Terry and I set out to a late-night hardware store and bought tubing which we hacked up in the parking lot with a newly acquired saw (to make it fit into my Honda) and would later reassemble in the show area and drape a background from it. It was very unstable, but, then again, the same is often said about us. This was our first ‘Fest with a full booth!

– What is Sub-Etha Software flyer, October 1994.

We sold many copies of it. Did you buy one? If so, any chance you could find it and send me a disk image of it? While the source code is likely lost forever, I’d really like to get this item preserved in the Color Computer Archive site.

Thank you for your attention to this matter.

More Sub-Etha Software MM/1 source code on GitHub

2 Replies

I have located source code to some of the MM/1 programs I wrote. It is now uploaded to my GitHub page:

https://github.com/allenhuffman/SubEthaSoftware

This includes…

  • MiniBanners – ported from CoCo BASIC09 to the MM/1 BASIC by Joel Hegberg (he had an MM/1 and I didn’t)
  • MegaBanners – the updated banner program that made use of Joel’s excellent MFONTS library.
  • Towel – the EthaWin library disk utility.
  • TCWin – my termcap windowing system that simulated many of the CoCo and MM/1’s CGFX text windowing calls. This allowed me to port EthaWin stuff over to OSK and OS-9000 boxes running on terminals. (I even ported it to DOS at one point, but lost all that work in a laptop hard drive crash.)

If you have access to an MM/1, I’d love to know if any of this software can be built and ran.
